Problems with digital input of ESI Juli@ xte PCI Soundcard
I've got an ESI Juli@ xte PCI Soundcard and want to use it on Ubuntu 12.04 Server. It's going to be a capture device only. It's used in a small free radio station. I want to use two analog inputs to capture the live radio program and the digital spdif (coaxial) in for streaming via darkice (icecast2 client) at the same time.
I got the analog inputs working well with arecord, but I'don't have a clue how to use the coaxial spdif in for the stream at the same time. I tried different audio device settings, to stream the digital in, but with no success (plughw:0,1, iec958:0,0, dsnoop, dmix...).
Does anybody know how to detect the right device adress? Here are some more details:
root@audio:~# arecord -L
null Discard all samples (playback) or generate zero samples (capture)
default:CARD=Juli ESI Juli@, ICE1724 Default Audio Device
sysdefault:CARD=Juli ESI Juli@, ICE1724 Default Audio Device
front:CARD=Juli,DEV=0 ESI Juli@, ICE1724 Front speakers
surround40:CARD=Juli,DEV=0 ESI Juli@, ICE1724 4.0 Surround output to Front and Rear speakers
surround41:CARD=Juli,DEV=0 ESI Juli@, ICE1724 4.1 Surround output to Front, Rear and Subwoofer speakers
surround50:CARD=Juli,DEV=0 ESI Juli@, ICE1724 5.0 Surround output to Front, Center and Rear speakers
surround51:CARD=Juli,DEV=0 ESI Juli@, ICE1724 5.1 Surround output to Front, Center, Rear and Subwoofer speakers
surround71:CARD=Juli,DEV=0 ESI Juli@, ICE1724 7.1 Surround output to Front, Center, Side, Rear and Woofer speakers
iec958:CARD=Juli,DEV=0 ESI Juli@, ICE1724 IEC958 (S/PDIF) Digital Audio Output
dmix:CARD=Juli,DEV=0 ESI Juli@, ICE1724 Direct sample mixing device
dmix:CARD=Juli,DEV=1 ESI Juli@, ICE1724 IEC958 Direct sample mixing device
dsnoop:CARD=Juli,DEV=0 ESI Juli@, ICE1724 Direct sample snooping device
dsnoop:CARD=Juli,DEV=1 ESI Juli@, ICE1724 IEC958 Direct sample snooping device
hw:CARD=Juli,DEV=0 of different also-tool outputs: ESI Juli@, ICE1724 Direct hardware device without any conversions
hw:CARD=Juli,DEV=1 ESI Juli@, ICE1724 IEC958 Direct hardware device without any conversions
plughw:CARD=Juli,DEV=0 ESI Juli@, ICE1724 Hardware device with all software conversions
plughw:CARD=Juli,DEV=1 ESI Juli@, ICE1724 IEC958 Hardware device with all software conversionscat /proc/asound/cards
root@audio:~# cat /proc/asound/cards 0 [Juli ]: ICE1724 - ESI Juli@ ESI Juli@ at 0xc0e0, irq 10If you need more information, please let me know.
