I've a VirtualBox VM which configured a very large hard disk size (bigger than host). By my mistake, a program on the VM generated lots of log files and the VDI file size keeps growing until there is no space on the host.

Now I've deleted the log files but the VDI file size are not getting smaller after using VBoxManage.exe modifyhd "C:\Virts\mybox-i386.vdi" compact

Is there a way to really compact the VDI file size? Thanks!

0

9 Answers

You have to do the following steps:

1. Run defrag in the guest (Windows only)

2. Nullify free space:

   With a Linux Guest run this:

    dd if=/dev/zero of=/var/tmp/bigemptyfile bs=4096k ; rm /var/tmp/bigemptyfile

   Or:

    telinit 1 mount -o remount,ro /dev/sda1 zerofree -v /dev/sda1

   With a Windows Guest, download SDelete from Sysinternals and run this:

    sdelete.exe c: -z

(replace C: with the drive letter of the VDI)

3. Shutdown the guest VM

4. Now run VBoxManage's modifymedium command with the --compact option:

   With a Linux Host run this:

    vboxmanage modifymedium --compact /path/to/thedisk.vdi

   With a Windows Host run this:

    VBoxManage.exe modifymedium --compact c:\path\to\thedisk.vdi

   With a Mac Host run this:

    VBoxManage modifymedium --compact /path/to/thedisk.vdi

   VBoxManage is located here: /Applications/

This reduces the vdi size.

58

I'm on a Windows 7 host with Windows guests, Here is a batch file I wrote to Compact all of the VDIs in a folder tree

echo off
mode con:cols=140 lines=200
cls
:: see
:: How can I reduce the size of a dynamic VDI on disk?
:: but that page says to use sdelete -s which is suboptimal.
:: use -z as per
:: First run the sdelete -z c: inside the VMs that zero-out all the free space
:: THEN run this batch file
Title Compacting Free space on Virtual Machine VMs
::
::
Setlocal EnableDelayedExpansion
:: ...
:: Notice that within the for loop we use !variable! instead of %variable%.
For /R %CD% %%G IN (*.vdi) DO ( set ohai=%%G set lastfive=!ohai:~-5!
:: Skip snapshots which are named {guid}.vdi if NOT !lastfive!==}.vdi ( echo . echo Compacting %%G "C:\Program Files\Oracle\VirtualBox\VboxManage.exe" modifyhd "%%G" --compact ) )
pause
exit

I left the links in the comments so you can (sort of) tell how it works.

edit

Well, after all that, I tried the CloneVDI tool and it did a good job in much less time and in one click.

5

Debian guest on Windows host using discard/TRIM.

This isn't a direct answer per se, as I'm addressing the problem, not the question. Instead of periodically compacting the image, this solution uses discard to automatically remove unused blocks in the host's VM disk image.

This solution requires a guest filesystem that supports continuous TRIM. The Arch Linux wiki has a list of filesystems supporting TRIM operations.

FDE and cryptoroot are specifically not covered, as there are security concerns and none of the other solutions to this question would allow compacting either. The Arch Linux wiki has information about TRIM and dm-crypt devices.

In theory, this will work for all Linux guests on VBox hosts using VDI storage.

Host configuration

With VBox exited and no VMs running, add discard support to your disks by setting both discard and nonrotational for each disk in the config file for the VM. At this time discard is not in the GUI, but nonrotational is exposed as the "Solid-state Drive" checkbox. (ref: vbox forums, discard support)

<AttachedDevice discard="true" nonrotational="true" type="HardDisk" [..other options..] >

Boot the VM up, and verify that TRIM support is enabled:

sudo hdparm -I /dev/sda | grep TRIM

Guest Configuration

If LVM is in use, change the discard setting in /etc/lvm/lvm.conf. (ref: debian wiki, lvm.conf example)

devices {
... issue_discards = 1
}

In fstab, add the discard option to the filesystems you wish to auto-discard (ref: debian wiki, fstab example)

UUID=8db6787f-1e82-42d8-b39f-8b7491a0523c / ext4 discard,errors=remount-ro 0 1
UUID=70bfca92-8454-4777-9d87-a7face32b7e7 /build ext4 discard,errors=remount-ro,noatime 0 1

Remount the filesystems to have them pick up their new options.

sudo mount -o remount /
sudo mount -o remount /build

Manually trim free blocks now with fstrim. fstrim uses the mounted filesystem, not the block device backing it. Instead of setting continuous discard in fstab, this could be done on a weekly cron. (The weekly cron is recommended for physical SSDs which may have questionable support for TRIM, but this is not relevant here since underlying SSDs are handled by the host OS. see: ssd trim warning).

fstrim /
fstrim /build

At this point, the size of the filesystems inside the VM and the size of the VM images should be pretty close in value.

Tested with:

• Guest1: Debian 8.7, kernel: linux 4.8 grsec from backports, filesystem: ext4
• Guest2: Debian 9 RC2, kernel: linux 4.9, filesystem: ext4
• Host1: VBox 5.1.14, Win7, image fmt: VDI
• Host2: VBox 5.1.14, Win8.1, image fmt: VDI

1

For MacOS Guest do this:

1. Nullify free space in guest system:

   diskutil secureErase freespace 0 "/Volumes/Macintosh HD"

   (replace /Volumes/Macintosh HD with your drive name)

2. Shutdown the guest VM

3. Run this command to reduce VDI disk image size

   VBoxManage modifyhd /path/to/thedisk.vdi --compact

   OR

   VBoxManage modifymedium /path/to/thedisk.vdi --compact

IMPORTANT NOTE FOR LEGACY (~1997-2007) OPERATING SYSTEMS

In general, the techniques in the answers previously given are valid; HOWEVER, there is a very important special case.

For a period of some years-- perhaps 1997-2007 or so-- 32-bit operating systems were still the norm, but hard disks larger than 2GB were already in use. As a result, when attempting to consume all free space by writing a file of zeroes (which should always be done as root, to include root's privileged free space, which no one else can touch), you may see:

File too large

instead of what you expect:

No space left on device.

If this occurs, you have most likely hit a 2GB file size limitation. This was common at the time because many file operations returned results in signed 32-bit integers, so that negative values could report error codes. This effectively meant that offset results were limited to 2^31 bytes without special measures.

The workaround is straightforward: keep creating separate, differently-named zeroing files until the disk actually runs out of space.

If you are an instructor wishing to demonstrate this situation for a class, a 4GB disk image with an old copy of Red Hat Linux 7.0 is sufficient.

1

I use this for my VDI image mounted to virtual Debian in Windows VirtualBox. It isn't a general solution, but it should at least give you a gist of what I do.

Commands in Debian:

root@debian:~# lsblk # show partitions

NAME MAJ:MIN RM SIZE RO TYPE MOUNTPOINT
sdb 8:16 0 128G 0 disk
└─sdb1 8:17 0 128G 0 part /mnt/web # THIS IS THE PARTITION OF INTEREST!
sda 8:0 0 64G 0 disk
├─sda1 8:1 0 61,4G 0 part /
├─sda2 8:2 0 1K 0 part
└─sda5 8:5 0 2,7G 0 part
[SWAP] sr0 11:0 1 56,3M 0 rom

root@debian:~# service mysql stop # terminate all operations with partition
root@debian:~# service apache2 stop # terminate all operations with partition
root@debian:~# umount /mnt/web # unplug partition
root@debian:~# apt-get install zerofree # install tool for filling in zeros to empty space
root@debian:~# zerofree -v /dev/sdb1 # fill with zeros
root@debian:~# poweroff # shut down machine

Commands in Windows:

C:\Program Files\Oracle\VirtualBox>VBoxManage.exe modifyhd --compact "D:\VirtualBox VMs\web.vdi" # convert zeros to empty space

Hope it helps :)

I don't want to enable TRIM support in OS, because every data deletion will force data compacting in VDI file, making guest system unusable when VDI file is on classic rotational disc. For me better is to perform compacting by hand e.g. once per month.

During normal compacting, VDI file content is copied to new file. This requires some (sometimes big) free space on host disc.

I've solution similar to pointed by Andrew Domaszek. It works very well even with NTFS (Windows10).

To do this:

• create new virtual machine which boots with GParted Live CD (you can use your favorite Linux distro).
• Edit machine settings and set SATA disc controller
• Add existing VDI files which you want to compact

• Change VDI based discs to be visible as SSD with TRIM support:

  VBoxManage storageattach "gpared live" --storagectl "SATA" --port 0 --discard on --nonrotational on
  VBoxManage storageattach "gpared live" --storagectl "SATA" --port 1 --discard on --nonrotational on

• start machine

• In Linux root shell, mount NTFS partition mount /dev/sda2 /mnt
• zero free space dd if=/dev/zero of=/mnt/bigfile
• rm /mnt/bigfile
• force compacting VDI without creating new file: fstrim -v /mnt

A very neat trick to supplement the accepted answer is that you can get away without doing any compacting at all after zeroing guest space, by using a compressed file system on the host (e.g. selecting to compress the folder of virtual drives on NTFS properties on a Windows host). This in fact has the benefit to save a lot more space because operating systems tend to hold a lot of repetitive text or binary files (e.g. a 30GB guest drive that had 15GB of space zeroed can turn to 4GB on the host drive).

Caveats include that drive access on the real hardware may increase and there is a slight increase in CPU usage.

Just to add an alternative to the accepted answer: vboxmanage clonehd not only clones but also compacts virtual disks, so if you also need to clone it you can use a similar process and do it in one go (in my case I was moving the VM from an external disk to an internal disk with less space so I needed clone+compact):

1. run defrag in the guest (Windows only)
2. zero-out free space in the guest
3. shutdown the guest VM
4. vboxmanage clonehd /mnt/externaldisk/VMs/win10.vdi /home/myuser/VMs/win10.vdi
