how to calculate the integral of $\sin^2(x)/x^2$ [duplicate]

$\begingroup$

Possible Duplicate:
Proof for an integral involving sinc function
How do I show that $\int_{-\infty}^\infty \frac{ \sin x \sin nx}{x^2} \ dx = \pi$?

$\int_{-\infty}^{\infty}\sin^2(x)/x^2=\pi$ according to wolfram alpha. That is such a beautiful result! But how do I calculate this integral by hand?

Thanks in advance.

$\endgroup$ 3

4 Answers

$\begingroup$

An easy way:

$$I(a)=\int_{-\infty}^{\infty}\frac{\sin^2(ax)dx}{x^2}$$

$$\implies \frac{dI}{da}=\int_{-\infty}^{\infty}\frac{\sin(2ax)dx}{x}=\pi$$

$$\implies I(a)=\pi a+const$$

$$\implies I(a)=\pi a$$ because $I(0)=0$

$\endgroup$ 1 $\begingroup$

First we split $\sin^2(x)=\frac{(1-e^{2ix})+(1-e^{-2ix})}{4}$. To avoid the pole at $x=0$, drop the path of integration a bit below the real line (this function has no poles and it vanishes at infinity, so this is okay).

Next, let $\gamma^+$ be the path below the real axis, then circling back in a semi-circular path counterclockwise around the upper half-plane; and let $\gamma^-$ be the path below the real axis, then circling back in a semi-circular path clockwise around the lower half-plane.

$\hspace{4cm}$

Note that $\gamma^+$ circles the pole at $x=0$ of $\frac{(1-e^{2ix})}{4x^2}$ and $\gamma^-$ misses the pole at $x=0$ of $\frac{(1-e^{-2ix})}{4x^2}$.

Therefore, $$ \begin{align} \int_{-\infty}^\infty\frac{\sin^2(x)}{x^2}\mathrm{d}x &=\int_{-\infty-i}^{\infty-i}\frac{1-\cos(2x)}{2x^2}\mathrm{d}x\\ &=\int_{-\infty-i}^{\infty-i}\frac{(1-e^{2ix})+(1-e^{-2ix})}{4x^2}\mathrm{d}x\\ &=\color{green}{\int_{\gamma^+}\frac{(1-e^{2ix})}{4x^2}\mathrm{d}x}+\color{red}{\int_{\gamma^-}\frac{(1-e^{-2ix})}{4x^2}\mathrm{d}x}\\ &=\color{green}{2\pi i\frac{-2i}{4}}+\color{red}{0}\\ &=\pi \end{align} $$

$\endgroup$ 6 $\begingroup$

Use Parseval theorem $\int_{-\infty}^{\infty}dx |f(x)|^{2}= \int_{-\infty}^{\infty}du|F(u)|^{2} $

the Fourier inverse transform of $ \frac{sin(x)}{x} $ is an step function (window function )

$\endgroup$ $\begingroup$

This is, for example, Exercise 2 of chapter 11 of the book Complex analysis by Bak and Newman. The hint is: integrate $$\frac{e^{2iz}-1-2iz}{z^2}$$ around a large semi-circle.

$\endgroup$
